iC2-30 3~ 380–480 V AC 37 A, 18.5 kW with filter
Product ID 132L6138
Image for illustration purposes only
Fast and reliable worldwide shipping with DHL Express
Europe
1 working day
North & South America
2 working days
Africa
3 working days
Asia
3 working days
- ID132L6138
- MMCIC2-30FA3N04-37A0E20F2+ACBC
- Manufacturer Danfoss
- Nominal power 18,5 kW
- Supply voltage 380–480 V AC
- Nominal current 37 A
- Number of phases 3~
Danfoss iC2-Micro is a general-purpose drive that is suitable for a wide and varied range of industrial and HVAC applications. iC2-Micro performs with unmatched reliability even in complex applications. It offers user-friendliness, condensed functionality, and easy commissioning, all in a powerful compact package.
In stock
Shipping next working day from our EU distribution hub
1 566,77 €
excl. VAT
Danfoss
Old product versions
This product is no longer available. It has been replaced by a new version
, which is its fully adequate replacement with identical parameters. Therefore, it is possible to replace the original product with the new one.
Need help?
Product description
Danfoss iC2-Micro is a general-purpose drive that is suitable for a wide and varied range of industrial and HVAC applications. iC2-Micro performs with unmatched reliability even in complex applications. It offers user-friendliness, condensed functionality, and easy commissioning, all in a powerful compact package.
MAIN FEATURES
- Fast and accurate installation with spring type I/O terminals for minimal external wiring.
- Fast commissioning thanks to application wizards and online/offline PC configuration tool.
- High reliability.
- Cost-effective and space-efficient investment with less wiring, side-by-side mounting and compact footprint.
- Compatible with all typical motor technologies.
- Supported by the powerful MyDrive® Suite digital tools.
- Optional external control panel provides extra features to ease commissioning, such as parameter copy and download.
Details
| Nominal power | 18,5 kW |
| Supply voltage | 380–480 V AC |
| Nominal current | 37 A |
| Number of phases | 3~ |
| Model series | iC2-Micro |
| Brake chopper | Yes |
| Digital inputs | 5 |
| Digital outputs | 1 |
| Analog inputs | 2 |
| Analog outputs | 1 |
| Relay outputs | 1 |
| EMC filter | C2 |
| Enclosure size | MA05a |
| Dimensions | 335mm x 165mm x 248,98mm |
| IP rating | IP20 |
| Weight (brutto) | 9500 g |
