• ID151F5106
  • Manufacturer White Drive Motors & Steering
  • Mounting flange 4 Bolt - Square
  • Mounting thread dimension Pilot dia. 82,5 x 6,1 mm - B.C. dia. 106,4 mm - Dia. 13,6 mm
  • Shaft style Straight
  • Shaft size Dia. 32 mm - M8 tap
  • Displacement 315 cm³
Reliable OMS orbital hydraulic motor manufactured by White Drive Motors & Steering (former Danfoss and Sauer-Danfoss) for use in open loop or closed loop hydraulic system.
In stock Shipping next working day from our EU distribution hub European Union
762,05 € excl. VAT 922,08 € incl. VAT
pc
Need help?

Product description

Robust OMS orbital hydraulic motor manufactured by White Drive Motors & Steering (former Danfoss and Sauer-Danfoss) for use in open loop or closed loop hydraulic system. Reliable motor designed for particularly rough operating conditions.

OMS orbital motors are known for their flexible use in many different applications. Their advantages include reliable operation, high efficiency under high pressure, three-zone design and optional high pressure shaft seal.

OMS MAIN FEATURES

  • Displacement 80-500 cm³
  • Max. continuous pressure 210 bar
  • Max. continuous torque 865 Nm
  • Max. continuous flow 75 l/min
  • Available with standard, short, ultra short and wheel mount options
  • Available with speed sensor
  • Available with ATEX certificate

Details

Basic motor OMS
Series O-series
Displacement 315 cm³
Shaft style Straight
Shaft size Dia. 32 mm - M8 tap
Mounting thread dimension Pilot dia. 82,5 x 6,1 mm - B.C. dia. 106,4 mm - Dia. 13,6 mm
Mounting flange 4 Bolt - Square
Shaft key A10 x 8 x 45 mm
Port style Side ported - offset manifold (2 x M10)
Port dimension G 1/2
Drain port style Standard - mounting flange
Drain port dimension G 1/4
Dust seal Standard
Shaft seal NBR - High pressure
Seal kit product ID 151F0111
Front bearing Tapered roller bearing
Rear bearing Tapered roller bearing
Gear wheel set Standard
Check valve Yes
Painted Black
Weight (brutto) 12300 g
